Temperature Maintain |
|
-400C (Working Temperature -320C to 360C) |
| |
|
|
|
| |
Construction |
|
○ Exterior is made out of G CRCA MS sheet
with two coats of primer and 3 coats of paint
(DUCO Paint)
○ Door is fitted on the chamber by heavy-duty
hinges and locking arrangement.
○ Gasket on the door
○ The chamber is constructed in double wall,
○ Interior is made of Stainless Steel,
○ The Unit is fitted with Lockable Castor
wheels for ease of mobility.
○ PUFF insulation in between |
| |
|
|
|
| |
Opening Door ( Double ) |
|
The chamber provides with a full front opening double wall typed PUFF insulated door. |
| |
|
|
|
| |
Insulation |
|
Puff Insulation for better power purpose |
| |
|
|
|
| |
Temp. Controller
& Control panel |
|
○ PID (Programmable) Microprocessors Based
Digital Temperature Controller cum Indicator
used for controlling -400C
○ Least Count : 0.10 C,
○ Accuracy = 0.1%,
○ Temperature Deviation of Maximum ±3k,
○ Digital Display
○ Controlled to Compressor,
○ Temperature Stability in Sample over time
Less than ±0.1k,
○ Audio Visual Alarm on High & Low
Temperature & on Power Failure, |
| |
|
|
|
| |
Temperature Recorder |
|
Microprocessor Based Circular Automatic Temperature Chart Recorder (Weekly) |
| |
|
|
|
| |
Inspection Lamp |
|
One low watt bulb for internal inspection automatically / manual operated, |
| |
|
|
|
| |
Cooling Unit |
|
Copeland ISI make Compressor, which is CFC Free refrigeration System. |
| |
|
|
|
| |
Power Supply |
|
220 - 240 Volts, Single Phase 50HZ, |
| |
|
|
|
| |
Voltage Stabilizer |
|
○ Capacity : 3KVA
○ Electronic safety device to be incorporated .
○ High & Low Voltage Protector
○ Other Safety Features. |
| |
|
|
|
