○ Constructed in double wall-PUF\
Insulated.
○ Interior : Stainless Steel 22 G
○ Exterior : G CRCA
MS Sheet 1.2 mm
○ Full front opening door.
○ Corner of outer body should be
rounded
○ Doubled walled typed with transparent
full view
○ Toughened double glass door. Glass
Size : 558 mm x 335 mm x 6 mm
○ Door : fitted on the chamber by
heavy-duty hinges.
○ Paint : Three coated DECO
Paint, Non scratch able,
○ Imported look,
○ Locking arrangement.
○ Gaskets on the door.
○ Fitted with Castor lockable
wheels for ease of mobility
Internal Size W x D x H
385 x 435 x 640 in mm approx
Capacity in Blood Bags
50-60 Standard Blood Bags
Digital Temp. Controller
Microprocessor Based Digital Temperature Controller cum Indicator used for controlling 4o to
60C ± 1o C, accuracy : 0.1o C, Fan Fitted in the Inner side for proper air circulation in chamber
Air circulation
Having provision for Air Circulation through internal fan facility. Temp gradient less than 0.5° C
Inspection Lamp
One low watt bulb for internal inspection automatically / manual operated,
Cooling Unit
Kirloskar / Copeland ISI Mark Compressor, which is CFC Free. Condenser & Cooling unit
should be made of copper tube & aluminum finns.
Weight of unit
Approx 120 kg
Power Supply
230 Volts, Single Phase 50HZ,
Trays / Shelves
No of Trays 3 in S.S. for proper Storage of blood bags. It is fitted on Imported Telescopic
Channels.
Size of Tray / Shelve
W x D x H : 305 x 355 x 88 in mm approx
Safety
○
Audiovisual alarming case of power failure,
opening the Door, & in case of high & Low
internal temperature of BBR.
○ Electronic safety device.
○ Low & High Voltage
protector.
Optional Accessories
1.Weekly Circular Chart Recorder
For Continuous
Temp. Recording Weekly Temperature Circular Chart
Recorder (Range 0oC to + 10oC),
Accuracy: 0.2oC,for Temp. Display visually & for continuous temperature
monitoring.
2. Voltage Stabilizer
