Sealing Time: |
|
0.6 to 2 Second |
| |
|
|
|
| |
Tubing Diameter: |
|
2 to 8 mm |
| |
|
|
|
| |
Dimension: |
|
300 (L) x 175 (W) x 150 (H) |
| |
|
|
|
| |
Construction: |
|
Made of Aluminum Alloy casting material duly polished. |
| |
|
|
|
| |
Operating Temperature: |
|
0 – 400C (32 to 104
0F), |
| |
|
|
|
| |
Type of Sealing: |
|
RF. Di – Electric |
| |
|
|
|
| |
Operation: |
|
Fully Automated portable, Continuous operation. It is suitable for Bench Top
Use. |
| |
|
|
|
| |
Warm Up time: |
|
No warm up time |
| |
|
|
|
| |
Power Supply |
|
220 – 240 Volts, Single Phase 50/60HZ |
| |
|
|
|
| |
Power Consumption |
|
30 W |
| |
|
|
|
| |
Safety Standards |
|
Having Electrical Safety Standards Protection against Electrical Chock &
Safety Fudge System |
| |
|
|
|
| |
Quality of Seal: |
|
Wide 3 mm & hermetic seal on the tube for easy sepration of two ends |
| |
|
|
|
| |
Working: |
|
On Radio Frequency which is MOSFET based Output: 70 W & Operating
Frequency 40.68 MHz crystal controlled electrical safety – internal power
supply. |
| |
|
|
|
| |
Security provisions: |
|
Shock proof sealing handle device & plastic cover on the electrodes to avoid
contact with |
| |
|
|
|
| |
Sensitivity |
|
Sealer equipped with sophisticated sensing system |
| |
|
|
|
| |
Maintenance |
|
It is easy to clean the electrodes by removing the covering lid on the
electrodes. |
| |
|
|
|
| |
Sealing |
|
Sealer has intelligent sensing system for better sealing. |
| |
|
|
|
| |
Weight |
|
5 kg approx. |
| |
|
|
|
| |
Battery backup |
|
Cadmium free NiMH batteries Rechargeable and Maintenance Free Battery
12V DC – Capacity : 1100 to 1400 Blood Tube Seals. |
| |
|
|
|
| |
Certifications |
|
ISO Certified, SSI, NSIC (Central Govt Enterprises), |
| |
|
|
|
